Silo system structure
The expandable silo system is constructed in a honeycomb pattern on an area measuring just 10 x 12 m. Depending on the silo volume, the construction height ranges between 18 m (50 m³ silo volume) and 30 m (90 m³ silo volume). The basic equipment comprises three silo chambers with round side walls made of high-quality steel or stainless steel. A large silo with a double chamber forms the centre of the system, around which up to eight additional daughter silos can be built in a circular formation. The system's extensions thus provide a quick and uncomplicated solution to additional raw material requirements and an increase in dosing capacity.
The basic module of the modular silo system contains the dosing units ...Product Expert
